主要技术参数 |
SRC47---IINP |
SRC56---IINP |
|
最大用纸尺寸 |
470*365mm |
560*400mm |
|
Max.paper size |
470*365mm |
560*400mm |
|
最大印刷面积 |
450*345mm |
550*375mm |
|
Max.printing area |
450*345mm |
550*375mm |
|
用纸克重 |
40----250g/㎡ |
40----250g/㎡ |
|
Paper weight |
40----250g/㎡ |
40----250g/㎡ |
|
印刷速度 |
2000---7500张/小时 |
2000---7500张/小时 |
|
Printing speed |
2000---7500sheet/hour |
2000---7500sheet/hour |
|
印版尺寸 |
460*395*0.15mm |
560*420*0.15mm |
|
Plate size |
460*395*0.15mm |
560*420*0.15mm |
|
橡皮布尺寸 |
470*430*1.95mm |
560*430*1.95mm |
|
Blanket size |
470*430*1.95mm |
560*430*1.95mm |
|
靠版棍数量 |
二墨一水 |
二墨一水 |
|
Form roller quantity |
two inking,one water |
two inking,one water |
|
功率 |
1.65kw |
1.65kw |
|
Power |
1.65kw |
1.65kw |
|
电源 |
220v/50hz |
220v/50hz |
|
Supply |
220v/50hz |
220v/50hz |
|
机器重量 |
1000kg |
1150kg |
|
Machine weingt |
1000kg |
1150kg |
|
外型尺寸 |
2040*950*1300mm |
2450*970*1340mm |
|
Overall dimensions |
2040*950, *1300mm |
2450*970*1340mm |
